Multiple display

No

Maximum voltage measuring range AC

1000 V

Maximum voltage measuring range DC

1500 V

Max. current measuring range, AC

2 A

Max. current measuring range, DC

2 A

Max. resistance measuring range

60 MOhm

Milliohm measurement with 4 wire technique

No Kelvin connection

Temperature measurement

Yes

Temperature measurement RTD

No

Temperature measurement TC

Yes

Max. temperature measuring range

1300 °C

Capacitance measurement

Yes

Max. capacitance measuring range

60000 µF

Frequency measurement

Yes

Max. frequency measuring range

10000 kHz

Resistance test/diode test

Yes

Nominal test voltage 10 V

No

Nominal test voltage 50 V

No

Nominal test voltage 100 V

No

Nominal test voltage 250 V

No

Nominal test voltage 500 V

No

Nominal test voltage 1000 V

No

Cable length measurement

No

Cable symmetry testing for two wire connections a-b-E

No

Power and energy measurement

No

Harmonics analysis/power quality

No

With decibel measurement

No dB

Relative value measurement

No

Inductance measurement

No

With conductivity measurement

No

Continuity test

Yes

Data hold

Yes Data Hold

Max. value storage

No

Min. value storage

No

Peak value memory

No

True RMS measurement

Yes TRMS

Duty cycle measurements

Yes

Rotational speed measuring

No

Measured value memory

Yes

Interface

No

Bluetooth interface

No

IR interface

No

Automatic circuit breaker

Yes

Max. voltage measuring circuit category

1000 V

Explosion-proof execution

No

With display backlight

Yes

High voltage test for motor windings

No

COFRAC certified

No

Relative measurement accuracy

0.8 %

Maximum voltage measuring range AC/DC

1500 V

Max. current measuring range, AC/DC

2 A

Calibration certificate according to DAkkS

No

Scaling bar graph linear

No

Calibration according to ISO/IEC 17025

No

Scaling bar graph logarithmic

No
