Two-pole Voltage Tester
TESTBOY PROFI III LED
Two-pole voltage tester
The new Testboy Profi III LED is the consequential further development of our popular Testboy Profi LED Plus. It convinces due to its user-friendly handling, the robust, safe construction and conforms to all requirements placed on modern voltage testers by a specialist. Due to the high safety classification, CAT IV 1000 V, it is also suitable for measurements on hybrid and electric vehicles, as well as photovoltaic installations.
How you benefit
- Highest safety level CAT IV 1000 V
- Practical one-hand operation
- Robust, safe construction
- Testing without finger contact
- Indication of voltages also possible without battery
Specifications
| Technical Data | TESTBOY PROFI III LED |
|---|---|
| Display: | Optical, LEDs |
| Ranging: | automatic |
| Overload Category: | CAT IV 1000 V |
| Voltage Test: | 6 – 1000 V AC 6 – 1400 V DC |
| Continuity Test: | 0 – 200 kΩ optically/acoustically |
| Phase Indication: | > 100V AC |
| Diode Test: | Yes |
| Polarity: | Yes (+,- LED) |
| PELV indication: | optical and vibrating |
| Protection: | IP 65 |
| Standard: | EN 61243-3:2014 |
| Auto power-off function: | Yes |
| FI/RCD check test: | 30 mA at 230 V AC using two buttons |
| Power Supply: | 2 × 1.5 V AAA (indication of voltages also possible without battery) |
| Single-pole phase testing: | Yes |
| Two-pole phase sequence testing: | Yes |
| Measurement position lighting: | white LED |
| Measurement position lighting: | white LED |
| 4-mm test tip adapter: | Removable |
| Dimension: | 300 × 75 × 20 mm |
| Weight: | 270 g |
| Colour: | Red/black |
| Scope of delivery: | Incl. batteries |
| Supplies, Optional: | Carrying case |
