Current Measurement Clamps

TESTBOY TV 218

Digital miniature clamp meter

Small but oho! There is no reason for the digital miniature clamp meter, Testboy TV 218, to hide and, due to TrueRMS, provides exact measuring results, also at locations difficult to access. In addition, despite the compact construction, it is convincing with useful functions such as Data-Hold or Auto-Power-Off.

How you benefit

  • Extremely compact construction
  • True RMS
  • Data-Hold function

Specifications

Technical DataTESTBOY TV 218
Display:LCD with 3 3/4 Digits, 4000 counts
Overload Category:CAT III 300 V
Standard:EC/EN 61010-1 (DIN VDE 0411)
Data hold:Yes
AC Current:40 A, 200 A ; ±2,5 %, ±8 Digits
Auto power-off function:Yes
Operating temperature range:0 – 40 °C, <75 %RH
DC Current:40 A, 200 A ; ±3,0 %, ±5 Digits
Storage temperature range:-20 – 60 °C, <80 %RH
Sampling rate:3 times per second
Resolution:0.01 A at 40 A
0.1 A at 200 A
Max. jaw opening:Ø 21 mm
Power Supply:2 x 1,5 V; LR44
Dimension:155 x 50 x25 mm
Weight:95g
Colour:red/black
Scope of delivery:incl. batteries and system carrying case
TESTBOY TV 218

To Downloads!
